TMK 300 - Authentic And Original

  • TMK 300 Authentic And Original
  • TMK 300 Authentic And Original
  • TMK 300 Authentic And Original
  • TMK 300 Authentic And Original
  • TMK 300 Authentic And Original
  • TMK 300 Authentic And Original
  • TMK 300 Authentic And Original
  • TMK 300 Authentic And Original
  • TMK 300 Authentic And Original
  • TMK 300 Authentic And Original
  • TMK 300 Authentic And Original
  • Video Button Maxresdefault
  • Video Button Maxresdefault
  • Video Button Maxresdefault
Videos
Call for Price
 Get a Quote  Get Financed  Value a Trade  Contact Us  Book a Demo   Get Directions  Print
Overview
Authentic And Original

TMK 300 is the beginning of the TMK product family. TMK 300 has the widest attachment options of all TMK products, and that makes TMK 300 into one of the most versatile shears on the market. TMK 300 fits well to small scale users, thanks to its simple operating, and all the way to the professionals thanks to its high productivity.

Puu              Paino

       300 mm                           295 kg                                           5-20 tons

Our product family’s matriarch weighs only 295 kg, which makes it possible to use it even on a 5 ton excavator, but it also endures the stress from a 20 ton excavator. Thanks to the capsular structure and efficient blade, 300mm tree can be cut neatly. Shear can be used also in the bigger miniloaders and skid steers. Unlike the other models, TMK 300 can be equipped also with a delimber option. Recommended hydraulic pressure for TMK 300 is 220-280 Bars, depending on the chosen cylinder.
  Attachments


Solid extension beam

TMK 300 can be equipped with solid extension beam. Bolt attached plates enables the beam to be taken off easily, if it doesn’t suit the job at hand. Extension is a good fit especially with delimber, as it makes the motion faster and smoother thanks to longer reach. Solid extension was designed to work with tiltrotators to ensure that the sensitive hoses doesn’t get damaged in the bushes, but kept in a safe distance from the branches and minimize the damages.

Delimber

Delimbing gives the last touch to the tree clearing as well as the TMK 300 attachment package. TMK has the first easilly controllable delimber on the market without expensive feeding systems. Delimbing is smooth thanks to the diamond shaped delimber hole. This shape gives the shear a little room to tilt before snapping the tree with the blade. This way is ensured a fast and smooth motion, when the delimbing is fast and more importantly easy. In the nordic countries the delimber is really common attachment because of the demand of stripped trees. Delimber is also possible to use without electricity, and delimber is also easy to retrofit.

Hydraulic Extension Beam

Hydraulic extension beam is professionals choice. Attached to the quick hitch, the hydraulic extension produces the much needed extra reach to the professionals, without sacrificing the agility. Extension beam is about 2 meters long and extends another 1,6 meters. With hydraulic extension beam it’s possible to get about 3,6 meters of extra reach, depending on the place of the bracket. Using the extension is simple and going back to excavation jobs is fast and easy. In the designing process of the beam we have kept in mind the needed features at forest thinnings and clearences, and the machine fits to turn even in the tightest of places with the extension on. The heel of the extension is strengthed and can be used to help the excavator to move in challenging places.

Collector

The collector increases the productivity of the shear significantly. Collector works automatically open-close motion all the way to the point where the bunch is dropped. When the shear is closed, the collector opens up to the other side of the trees, and when the shear is opened again, the collector first grabs the trees firmly in its grip. This way the trees stay all the time firmly in hand. Only when the bunch is dropped one electric line is needed to let the bunch go from the grip. Collectors simple operation enables fast and comfortable working. Thanks to its high productivity, the collector is TMKs most popular attachment worldwide.

NEW! Collector is now available also without electricity! Ask more from your local dealer, or directly from TMK.

Linkage

TMKs Linkage brings more speed and versatility to TMK Tree  Shears use. Linkage was originally designed to speed up the working with hydraulic extension beam, but now it enables the shear to be used in machines that doesn’t have a feature to tilt  the shear up and down. Now we can offer a solution to use the shear with tractor cranes and  harvesters. Linkage tilts 165 degrees, which ensures wide movements and small enough cylinder keep the motion fast. Linkage is attached to the shear with bolts, so it can be taken off quickly and used again on a different machine when needed.

NEW! In cooperation with Palfinger we made a linkage that is fits directly to all EPSOLUTION series cranes! Ask more from your local dealer, or directly from TMK.

Cylinder Options

TMK 300 can be eqipped with different sylinder options.

1. Normal main cylinder, recommended pressure 280 Bars.
2. Bigger main cylinder, recommended pressure 220 Bars.
3. TMK Turbo is patented telescopic cylinder, where the smaller cylinder works always first, keeping the motion fast. When the smaller cylinder runs out of power, the bigger cylinder starts working automatically. This way we get really fast motion without sacrificing the strength at all. TMK Turbos’ recommended pressure is 220 Bars.

TMK Turbo and bigger main cylinder are excellent choices when working with tilt rotators, when the reduced pressure doesn’t affect the maximum cutting capability. TMK Turbo grows your work efficiency up to 15%!
   Technical Specifications:


Dimensions



Specifications
Model
300 - Authentic And Original
Year
2017
Sale Type
New
Manufacturer
TMK
